The INTERNET Database of Periodic Tables

There are thousands of periodic tables in web space, but this is the only comprehensive database of periodic tables & periodic system formulations. If you know of an interesting periodic table that is missing, please contact the database curator: Mark R. Leach Ph.D. The database holds information on periodic tables, the discovery of the elements, the elucidation of atomic weights and the discovery of atomic structure (and much, much more).

Periodic Tables from the year 1905 :

Werner's Arrangement

Werner's Arrangement is the first modern looking PT formulation. It appeared before the structure of the atom was known, before the importance of atomic number was recognised and before quantum mechanics had been developed.

Berichte der Deutschen Chemischen Gesellschaft (1905), 38, 914-21 and J. Chem. Soc., Abstr. 88, II, 308-9 1905:

From Quam & Quam's 1934 review paper.pdf

Eric Scerri comments that the interesting features are:

• A remarkably modern looking formulation in that it separates not only the transition metals but also the rare earths into separate blocks to give what we would now call a "long-form 32 column table". Except Werner guessed wrong as to how many rare earths exist, with the result that he shows 33 groups.
• This formulation is also interesting for showing an element between H and He and two elements before H.
• Werner computed the average gaps between atomic weights for the second through the fifth periods as 1.85, 2.4, 2.47 and 2.5, respectively.
• From this he extrapolated the gap for the first period as 1.5, which coincidentally was also half the difference between the atomic weights of H and He. Werner thus predicted a new element with atomic weight 2.5.
• Moseley's work of 1913 showed there were no elements before H and none between H and He.



Thanks to Eric Scerri for the tip!
See the website EricScerri.com and Eric's Twitter Feed.

Gooch & Walker Periodic Table

Mazurs' reproduction (p. 82) of a periodic table formulation by Frank Austin Gooch and Claude Frederic Walker, from Outlines of Inorganic Chemistry, Macmillan, London and New York, p. 8/9, 1905 (ref Mazurs p.188):

Thanks to Laurie Palmer for the tip, and to Philip Stewart for the corrections and details.

Gooch & Walker's Periodic System of The Elements

From a 1905 textbook by Gooch & Walker: Outlines of Inorganic Chemistry (see the Google Books scanned version pp273) comes an early 'right-step' periodic table. The formulation was reproduced in a 1917 textbook (lower image).

Thanks to Eric Scerri for the tip! See the website EricScerri.com and Eric's Twitter Feed

Gooch & Walker's Primary, Secondary, and Tertiary Series of Elements

This three dimensional formulation – clearly developed from the Crookes' vis generatrix model – is given a 1905 textbook by Gooch & Walker: Outlines of Inorganic Chemistry (see the Google Books scanned version pp273).

"The arrangement of the elements in three series of eight groups each may be represented by a model in which large and small wooden balls, on a spiral wire, represent the common and rare elements respectively; those balls falling in the same vertical column representing elements in the same groups":

Einsein's Annus Mirabilis

From Wikipedia:

The annus mirabilis papers (from Latin: annus mirabilis, 'miraculous year') are four papers that Albert Einstein published in the scientific journal Annalen der Physik (Annals of Physics) in 1905. As major contributions to the foundation of modern physics, these scientific publications were the ones for which he gained fame among physicists. They revolutionised science's understanding of the fundamental concepts of space, time, mass, energy, atoms and atomic structure.

1. Einstein, Albert (1905) Über einen die Erzeugung und Verwandlung des Lichtes betreffenden heuristischen Gesichtspunkt [On a Heuristic Point of View about the Creation and Conversion of Light] Annalen der Physik (in German). 17 (6): 132–148. doi: https://doi.org/10.1002%2Fandp.19053220607 English translation.

   The first paper explained the photoelectric effect, which established the energy of the light quanta, E = hf or E = hν (depending upon context), where h = Planck's constant. This was the only specific discovery mentioned in the citation awarding Einstein the 1921 Nobel Prize in Physics.



2. Einstein, Albert (1905) Über die von der molekularkinetischen Theorie der Wärme geforderte Bewegung von in ruhenden Flüssigkeiten suspendierten Teilchen [Investigations on the theory of Brownian Movement] Annalen der Physik (in German). 322 (8): 549–560. doi: https://doi.org/10.1002%2Fandp.19053220806

   The second paper explained Brownian motion, D = μk_BT which compelled physicists to accept the existence of atoms.



3. Einstein, Albert (30 June 1905) Zur Elektrodynamik bewegter Körper [On the Electrodynamics of Moving Bodies]. Annalen der Physik (in German). 17 (10): 891–921. doi: https://onlinelibrary.wiley.com/doi/10.1002/andp.19053221004 English tranlation

   The third paper introduced Einstein's special theory of relativity, which proclaims the constancy of the speed of light.



4. Einstein, Albert (1905). Ist die Trägheit eines Körpers von seinem Energieinhalt abhängig? [Does the Inertia of a Body Depend Upon Its Energy Content?] Annalen der Physik (in German). 18 (13): 639–641. doi: https://onlinelibrary.wiley.com/doi/10.1002/andp.19053231314 English translation

   The fourth, a consequence of special relativity, developed the principle of mass–energy equivalence, expressed in the equation E = mc², and which led to the discovery and use of nuclear power decades later.

These four papers, together with quantum mechanics and Einstein's later general theory of relativity (1916), are the foundation of modern physics.
